Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic

Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic

Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic
Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic

تصویر بزرگ :  Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic بهترین قیمت

جزئیات محصول:
Place of Origin: China(Mainland)
نام تجاری: V&H
گواهی: CE & ISO
Model Number: iCV200BLE
پرداخت:
Minimum Order Quantity: 1 set/sets
Packaging Details: standard package
Delivery Time: 7 working days after payment
Payment Terms: T/T, L/C, Western Union
Supply Ability: 50 sets per week
توضیحات محصول جزئیات
Product: 2017 latest 12 channel low power bluetooth ecg machine for clinic Type: Resting
Transfer Way: Bluetooth Defibrillation Protect: Build-in
Channel: Standard 12 channel Dynamic Range: ±15mV
Power: 2 AA Batteries Sampling Rate:: A/D: 24K SPS/Ch; Recording: 1K SPS/Ch
برجسته:

wireless ecg machine,cardiac monitoring equipment

,

cardiac monitoring equipment



2017 latest 12 channel low power bluetooth ecg machine for clinic



Advantages:

  1. The first professional elsctrocardiogram (ECG) product developed on IOS portable device.
  2. High-definition ECG display thanks to its Apple high resolution screen and anti-aliased algorithm.
  3. Automatic measurements and interpretations.
  4. Simultaneous 12-lead ECG
  5. Bluetooth communication

For analysis APP, Most of the ECG related Apps on App Store are for education or practice



iCV200BLE is for real heart disease diagnosis, and target for hospitals, healthcare organizations or Cardiology doctors



ECG Recorder Specifications



Sampling Rate

A/D:24K SPS/Ch

Recording:1K SPS/Ch

Quantization Precision

A/D:24 Bits

Recording:16 Bits

Common Mode Rejection >110dB
Resolution 0.4uV
Input Impedance >20M
Frequency Response 0.05-250Hz(±3bB)
Time Constant >3.2Sec
Maximum Electrode Potential ±300mV DC
Dynamic Range ±15mV
Power 2xAA Batteries
Communication Bluetooth
Defibrillation Project  Build-in









Standard 12 Channel ECG Machine Low Power Bluetooth Ecg Machine For Clinic





About Us

Vales and Hills Biomedical Tech.Ltd is a global provider centralizing of electrocardiograph(ECG) products and ECG web services for clinical applications. For over 10 years,we have been creating a complete CardioView product line which covers Portable ECG(IOS and Android ), PC-ECG,ECG Workstation,Holter,ABPM, ECG Network and ECG Cloud Service.



Which a pioneering spirit in technology innovation, V&H has set up a truly top-notch team with determination, conceived in collaboration, dedicated to the proposition that clients and people are the first to be focused on. We continue to invest in advanced technology to meet the ever-changing clinical needs of the market.
